Agilent 8565A Spectrum Analyzer 10 MHz - 40 GHz

• Description
• Features
• Specifications

Description

Covering from 0.01 to 22 GHz with its internal mixer, the HP 8565A has built-in preselection and brings accuracy plus convenience to microwave spectrum analysis. The wide range, spurious-free display, compact design and ease of use make it well suited for lab, production, or field applications requiring accurate measurement from IF through microwave frequencies. The HP 8565A can cover 0.01 to 22 GHz in just two spans for rapid location of signals prior to close-in analysis in one of six bands. Coverage is easily extended up to 40 GHz with the HP 11517A External Mixer.

Features

• 9 kHz to 50 GHz
•  +/-1.0 dB absolute amplitude accuracy
•  -149 dBm/Hz displayed average noise level (DANL)
•  <-113 dBm/Hz phase noise at 10 kHz offset
• Fast digital resolution bandwidths of 1 Hz to 3 MHz
• Portable, MIL-PRF-28800, Class 3 rugged
• Easily transfer screen image or trace data to PC with BenchLink software E4444A BenchLink
• Software
• Bench top
