Rohde & Schwarz FS300 Spectrum Analyzer 9 kHz – 3 GHz

Description

The R&S FS300 is a highly accurate spectrum analyzer with a frequency range of 9 kHz to 3 GHz. Owing to its modern, digital frequency processing technique; it offers high measurement quality at a favorable price. Whether on the lab bench, in service or as a flexible measuring instrument in automatic production systems, the range of applications is almost unlimited.

Features

  • High-quality measurement characteristics
  • Resolution bandwidths from 200 Hz to 1 MHz
  • Frequencies counter with 1 Hz resolution
  • Maximum input level 33 dBm
  • Ergonomic user interface
  • Remote control via USB interface
  • High picture refresh rate

Rohde and Schwarz FS300 Applications

  • Measurement of RF spectrum (level and frequency)
  • Measurement of radiated interference (EMC)
  • Applications in mobile radio and wireless
  • Communication (GSM, WCDMA, DECT, W-LAN, Bluetooth TM, etc)
  • TDMA power measurements
  • Radio monitoring remote-controlled via USB

Specifications

Frequency Range

9 kHz to 3 GHz

Resolution bandwidths (-3dB)

200 Hz to 1 MHz

Video bandwidths

10 Hz to 1 MHz

Displayed average noise level

< –110 dBm, typ. –115 dBm (300 Hz)

Intermodulation free range

< –70 dBc at –36 dBm input level

SSB phase noise, 10 kHz offset

< –90 dBc (1 Hz)

Level uncertainty

< 1.5 dB, typ. 0.7 dB

Detector

peak

Measurement functions

TOI, TDMA power, frequency counter, noise marker

Tracking Generator

-

Audio Frequency demodulator

-

Measurement with Antenna Factors

-

Standards

CISPR
CISPR 11
CISPR 14 - 1
CISPR 14 - 2
CISPR 14 - 2
CISPR 16 - 1
CISPR 16 - 2
CISPR 16 - 3
CISPR 16 - 4
CISPR 22
CISPR 24
IEC
IEC/TR EN 61000 - 1 - 1
IEC/TR EN 61000 - 2 - 1
IEC/TR EN 61000 - 2 - 3
IEC EN 61000 - 3 - 2
IEC EN 61000 - 3 - 4
IEC/TC EN 61000 - 3 - 5
IEC EN 61000 - 4 - 2
IEC EN 61000 - 4 - 3
IEC EN 61000 - 4 - 4
IEC EN 61000 - 4 - 5
IEC EN 61000 - 4 - 6
IEC EN 61000 - 4 - 7
IEC EN 61000 - 4 - 8
IEC EN 61000 - 4 - 9
IEC EN 61000 - 4 - 11
European
EN 50 081 part 1
EN 50 081 part 2
EN 55 011
EN 55 013
EN 55 014
EN 55 015
EN 55 020
EN 55 022
EN 55 024
EN 50 082 part 1
EN 50 082 part 2
EN 50 093
American
FCC Part 15
MIL-STD - 461E
