Keysight N9310A RF Signal Generator 9 kHz - 3 GHz

Description

Keysight N9310A RF signal generator covers a frequency range from 9 kHz to 3 GHz. With its low price, reliable performance, and straightforward functionality, it's well-suited for start-up R&D, service maintenance, manufacturing, and education.

There are some applications where basic functionality of a signal generator is all you need or want, such as the RX level test of a receiver, components characterization, and EMC test of a product. For those instances, the N9310A RF signal generator is ideal. You can count on the N9310A signal generator to provide the reliable performance you need that's just right for general purpose testing.

You also count on the N9310A signal generator to provide the functionality you need that's just essential for general purpose testing.

Features

  • 9 kHz to 3 GHz CW output, 20 Hz to 80 kHz low frequency (LF) output
  • -127 to +13 dBm output level range (maximum +20 dBm settable)
  • -95 dBc/Hz SSB phase noise
  • Full sweep function: RF (9 kHz to 3 GHz) /Amplitude (-127 to +13 dBm), LF (20 Hz to 80 kHz)
  • Extensive analog modulation: AM, FM, Phase, and Pulse modulation
  • Optional IQ modulator, 40 MHz bandwidth
  • Intuitive GUI offering 11 languages
  • Standard USB connectivity for test automation and flash memory support
  • SCPI command set for remote control

Specifications

Frequency coverage

9 KHz to 3 GHz with 0.1 Hz resolution

CW and analog modulations

CW, analog modulated (AM/FM/ØM) and pulse modulated signals

Wide bandwidth (40 MHz) IQ modulator

Enables digital modulated signals such as GSM, cdma, OFDM from your own custom IQ signals

Easy programmable control for automation SCPI command or with Virtual Panel software in PC environment

Usability

dual-language UI and USB connectivity for easy operation and data storage

Standards

CISPR
CISPR 11
CISPR 14 - 1
CISPR 14 - 2
CISPR 14 - 2
CISPR 16 - 1
CISPR 16 - 2
CISPR 16 - 3
CISPR 16 - 4
CISPR 22
CISPR 24
IEC
IEC/TR EN 61000 - 1 - 1
IEC/TR EN 61000 - 2 - 1
IEC/TR EN 61000 - 2 - 3
IEC EN 61000 - 3 - 2
IEC EN 61000 - 3 - 4
IEC/TC EN 61000 - 3 - 5
IEC EN 61000 - 4 - 2
IEC EN 61000 - 4 - 3
IEC EN 61000 - 4 - 4
IEC EN 61000 - 4 - 5
IEC EN 61000 - 4 - 6
IEC EN 61000 - 4 - 7
IEC EN 61000 - 4 - 8
IEC EN 61000 - 4 - 9
IEC EN 61000 - 4 - 11
European
EN 50 081 part 1
EN 50 081 part 2
EN 55 011
EN 55 013
EN 55 014
EN 55 015
EN 55 020
EN 55 022
EN 55 024
EN 50 082 part 1
EN 50 082 part 2
EN 50 093
American
FCC Part 15
MIL-STD - 461E
