Associated Research 7650 7kVAC, 5kVDC Hipot/Insulation Resist. Tester

Description

HypotULTRAî III, model 7650, is a 3-in-1 dielectric analyzer with an enhanced graphic LCD and analog bar graph. HypotULTRAî III provides AC/DC Hipot and Insulation Resistance testing. In addition, through the 2 kOhm test mode, it is able to perform point-to-point continuity and Hipot tests at voltages up to 5,000 volts with one set of test connections. It can be used as bench top instrument or as a PC controlled system used in tandem with our stand alone Autowareî control software. It is well suited for automated Hipot testing needs. Extended test capability is provided with the optional 4 or 8 port built-in scanning matrix and the 2 kOhm continuity test mode. The ability to perform multiple tests with a single connection will increase production and efficiency while saving time and money. The enhanced graphic greatly simplifies the user interface and makes testing safer, easier and more reliable than ever before.

Features

  • Patented SmartGFI® safety circuit protects the operator from shock hazards
  • Patented VERI-CHEK® feature prompts the users through steps to validate the instrument’s operation
  • Patented Prompt and Hold function provides a unique method for performing multiple steps during a test cycle
  • Patented CAL-ALERT® alerts the operator when the HypotULTRA III is due for re-calibration
  • RAMP HI® and CHARGE LO® for more effective DC Hipot testing
  • Two Continuity Test modes allow for simultaneous continuity tests during Hipot testing as well as point-to-point continuity testing
  • USB/RS-232, GPIB, Ethernet, or RS-485 automation interfaces available
  • Data Storage card available for storing and transferring test data without a connection to a PC
  • Graphic LCD and intuitive menu system to simplify the entire testing process from set-up to results
  • 50 memories with 30 steps per memory that can be stored and recalled in any alphanumeric combination
  • Real Current measurement allows operators to monitor total and real current ona single screen
  • Advanced functionality available with an optional 4 or 8 port internal scanner
  • Autoware Testing Software available for complete Automation Control
