Agilent DSO5032A 2 Channel 300 MHz 5000 Series Oscilloscope

Description

The InfiniiVision 5000 Series oscilloscopes leverage the same third generation MegaZoom III technology blocks used in our higher performance bench and lab oscilloscopes – responsive deep memory, fast update rates with minimal “dead time,” analog-like display systems, and integrated serial analysis – and deliver them in a compact package, at a price similar to oscilloscopes with older technology blocks.

Features

  • 300 MHz
  • 2 channels
  • 2 GSa/s sample rate
  • 8 Mpts acquisition memory standard
  • Up to 100,000 waveform per second real-time update rate
  • High-definition XGA (1024 x 768) display with 256 levels of intensity grading
  • USB (2 host ports, 1 device port), LAN, GPIB – 100 MBit LAN
  • XGA display out
  • Full remote control, including web browser
  • LXI-C compliant

Specifications

Frequency Range/ Bandwidth

300 MHz

Max. Vertical Sensitivity

5 V/div

Min. Vertical Sensitivity

1 mV/div

Number of Channels

2 CH

Other Features

USB, GPIB, LAN output - XGA Color 256 lev. intensity

Record Length

1 Mpts - optional 2 or 8 Mpts

Sample Rate

2 GSa/s

Type (D/A)

Digital

Standards

CISPR
CISPR 11
CISPR 14 - 1
CISPR 14 - 2
CISPR 14 - 2
CISPR 16 - 1
CISPR 16 - 2
CISPR 16 - 3
CISPR 16 - 4
CISPR 22
CISPR 24
IEC
IEC/TR EN 61000 - 1 - 1
IEC/TR EN 61000 - 2 - 1
IEC/TR EN 61000 - 2 - 3
IEC EN 61000 - 3 - 2
IEC EN 61000 - 3 - 4
IEC/TC EN 61000 - 3 - 5
IEC EN 61000 - 4 - 2
IEC EN 61000 - 4 - 3
IEC EN 61000 - 4 - 4
IEC EN 61000 - 4 - 5
IEC EN 61000 - 4 - 6
IEC EN 61000 - 4 - 7
IEC EN 61000 - 4 - 8
IEC EN 61000 - 4 - 9
IEC EN 61000 - 4 - 11
European
EN 50 081 part 1
EN 50 081 part 2
EN 55 011
EN 55 013
EN 55 014
EN 55 015
EN 55 020
EN 55 022
EN 55 024
EN 50 082 part 1
EN 50 082 part 2
EN 50 093
American
FCC Part 15
MIL-STD - 461E
